Motor/Control Division

Frame	90L/MS
Output	7.5 HP (5.5 kW)
Number of Poles	4
Frequency	60 Hz
Rated speed	1730 rpm
Slip	3.89 %
Rated voltage	208-230/460 V
Rated current	22.4-20.3/10.1 A
L. R. Amperes	184-166/82.8 A
LRC	8.2
No load current	0.000-10.0/5.02 A
Rated torque	22.8 ft.lb
Locked rotor torque	370 %
Breakdown torque	400 %
Locked rotor time	12s (cold) 7s (hot)

Design	N
Insulation Class	F
Service factor	1.00
Temperature rise	80 K
Duty Cycle	S6
Starting Method	Direct On Line
Ambient temperature	-20°C to +40°C
Altitude	1000 m.a.s.l.
Degree of Protection	IP54
Enclosure	IC411 - TEFC
Mounting	B3R(D)
Rotation¹	CW
Noise level²	55.0 dB(A)
Approx. weight³	165 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
83.5	85.0	85.3

Power factor

50%	75%	100%
0.60	0.74	0.80

Features

Frame Material	Cast Iron
Impregnation Method	Dip and Bake Polyester
Main terminal box hole	RWG(Rp) 1"
Terminal Block	Without
Shaft Material	SAE 1040/45 Carbon Steel
Painting	RAL 7022 207A (ISO 12944 - C2)
Grounding Lugs	Single
Fan Cover material	Cast Iron
Tropicalized Painting	Without
Fan material	Aluminum
Bearing cap	No-Without Bearing Cap
Balancing Method	1/2 Key
Drip Cover	Without
Overload protector (phenolic)	Without overload protector
Connection Cables Quantity	9
