/Products/Electric Motors/Single Phase Electric Motors/Marathon Single Phase Electric Motors/131526.00 Marathon 1.5HP Electric Motor, 1200RPM
Click Image to Expand

Product ID: 131526.00

131526.00 Marathon 1.5HP Electric Motor, 1200RPM

MFG: Marathon Electric
MFG Part Number: 131526.00

Selected accessories will also be added to cart
$1,199.97 / Each
Quantity:
C184C11FB2C, TEFC, 184T Frame, 115/208-230V
Features
  • Durable rolled steel construction
  • NEMA Design B performance
  • Double shielded ball bearings
  • Continuous duty
  • 1-year warranty on general purpose motors
General Specifications
Model :C184C11FB2C Catalog No :131526.00
Part Description :..1 1/2HP..1140RPM.184.TEFC.115/208-230V.1PH.60HZ.CONT.40C.1.0SF.RIGID.C184C11FB2C.....GENERAL PURPOSE.NOT....... Category :Totally Enclosed Fan Cooled (TEFC)
Stock :No
Nameplate Specifications
Output HP :1.5 Hp Output KW :1.12 kW
Frequency :60 Hz Voltage :115/208-230 V
Current :22/11 A Speed :1140 rpm
Service Factor :1 Phase :1
Efficiency :67 % Duty :CONTINUOUS
Insulation Class :F Design Code :L
KVA Code :J Frame :184T
Enclosure :TEFC Overload Protector :NOT
Ambient Temperature :40 ?C Drive End Bearing Size :6206
Opp Drive End Bearing Size :6205 UL :Recognized
CSA :Y CE :N
IP Code :43
Technical Specifications
Electrical Type :CAP START IND RUN Starting Method :ACROSS THE LINE
Poles :6 Rotation :SELECTIVE CCW
Mounting :RIGID Motor Orientation :HORIZONTAL
Drive End Bearing :BALL Opp Drive End Bearing :BALL
Frame Material :ROLLED STEEL Shaft Type :T
Overall Length :15.46 in Frame Length :10 in
Shaft Diameter :1.13 in Shaft Extension :2.75 in
Assembly/Box Mounting :F1 ONLY UPC :691720017760
Weight :75.00 LB
Speed Characteristics
CurvepointCurrent (Amps)Current (%)Torque (ft-lbs)Torque (%)Speed (RPM)Rated Output (KW)Power Factor (%)Rated Output (Hp)
Locked-Rotor50.7015.40228.001.50
Full Load11.006.75100.01,1661.50
Break-Down0.0014.50215.001.50
Pull-Up0.0011.00163.001.50
Load Characteristics
  • % of Rated Load
  • Current (Amps)
  • Rated Output (KW)
  • Efficiency (%)
  • Power Factor (%)
  • Speed (RPM)
  • Temp. rise @ FL
  • Torque (ft-lb)
  • 0 %
  • 8.30
  • 0.348
  • 0.0
  • 18.2
  • 1,193
  • 0.0
  • 0.00
  • 25 %
  • 8.45
  • 0.663
  • 43.4
  • 34.1
  • 1,190
  • 0.0
  • 1.70
  • 50 %
  • 9.00
  • 0.963
  • 59.3
  • 46.5
  • 1,183
  • 0.0
  • 3.40
  • 75 %
  • 9.80
  • 1.297
  • 65.7
  • 57.5
  • 1,175
  • 0.0
  • 5.10
  • 100 %
  • 11.00
  • 1.645
  • 68.0
  • 65.0
  • 1,166
  • 0.0
  • 6.75
  • 115 %
  • 13.60
  • 1.900
  • 68.0
  • 64.0
  • 1,170
  • 0.0
  • 7.80
  • 125 %
  • 12.50
  • 2.040
  • 67.6
  • 71.0
  • 1,156
  • 0.0
  • 8.40
  • 150 %
  • 14.45
  • 2.505
  • 65.4
  • 75.4
  • 1,141
  • 0.0
  • 10.10
Type
Electric Motor
Input Phase
Single Phase
Speed
1200RPM
Enclosure
TEFC
Horsepower
1.5HP
Frame
184T
