Brand Name MORSE® Cutting Tools
Class Regular Length
Decimal Equivalent 0.141
Diameter 9/64
End Type Center Cutting
Finish Bright
2-Flute

Double End Mills



High Speed Steel – Center Cutting

30° Helix Angle



2-Flute end mill provide increased chip capacity for higher feed rates.

Recommended for easy-to-machine materials including low alloy steels, non-ferrous materials and cast iron. Ideal for periphery cutting, slotting, and pocketing.

Center Cutting end allows for plunge cutting into solid material.

** When plunging feed rates usually need to be dropped to a 1/3 to a ½ of normal feedrates. **

Flute Length 13/32
Flute Type 30 Degree Helix
Harmonized Tariff Code 8207.70
List No. 1896
Material High Speed Steel
Number of Flutes 2
Origin Made In U.S.A.
Overall Length 2-1/4
Package Quantity 1
Shank Diameter 3/16
Style Finishing
Type Double End
UPC Code 686125434083
