/Products/Electric Motors/Single Phase/WEG Single Phase Electric Motors/Air Handling/.5018OS1AEC56 WEG 1/2HP Fan & Exhaust Electric Motor, 1800RPM
.5018OS1AEC56 WEG 1/2HP Fan & Exhaust Electric Motor, 1800RPM
Enlarge Photo

Product ID: .5018OS1AEC56

.5018OS1AEC56 WEG 1/2HP Fan & Exhaust Electric Motor, 1800RPM

MFG: WEG Electric Corporation
MFG Part Number: .5018OS1AEC56

Selected accessories will also be added to cart
$145.96 / Each
Quantity:
IC01 - ODP, IP21, E56 Frame, 115VAC 60Hz Single Phase, 12249623, Rolled Steel Frame, Footless, 1/2" Flatted Shaft

Electric Motors

FrameE56
Output0.37 kW (0.5 HP)
Number of Poles4
Frequency60 Hz
Rated speed1725 rpm
Slip4.17 %
Rated voltage115 V
Rated current8.20 A
L. R. Amperes54.9 A
LRC6.7x(Code P)
No load current7.50 A
Rated torque1.51 ft.lb
Locked rotor torque130 %
Breakdown torque260 %
Locked rotor time10s (cold) 6s (hot)
Moment of inertia (J)0.0712 sq.ft.lb
Insulation ClassB
Service factor1.00
Temperature rise80 K
Duty CycleCont.(S1)
Starting MethodDirect On Line
Ambient temperature-20°C to +40°C
Altitude1000 m.a.s.l.
Degree of ProtectionIP21
EnclosureIC01 - ODP
MountingF-1
Rotation¹CW
Approx. weight³19.8 lb
(1) Looking the motor from the shaft end.; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%75%100%
42.451.255.5

Power factor

50%75%100%
0.450.550.64

Features

Frame MaterialRolled Steel
Impregnation MethodDip and Bake Polyester
Shaft Locking DeviceWithout
Shaft MaterialSAE 1040/45 Carbon Steel
PaintingOnly primer
Grounding LugsSingle
Fan Cover materialWithout Fan Cover
Tropicalized PaintingWithout
Fan materialWithout fan
Bearing capNo-Without Bearing Cap
Winding thermal protectionThermostat - 2 wires 1 per phase 130°C
Balancing MethodNot Balanced
Drip CoverWithout
Resilient BaseWithout
Overload protector (phenolic)Without overload protector
Type
Electric Motor
Input Phase
Single Phase
Speed
1800RPM
Enclosure
ODP
Horsepower
1/2HP
Input Voltage
115VAC
Frame
E56
