Motor/Control Division

Frame	56
Output	0.5 HP (0.37 kW)
Number of Poles	2
Frequency	60 Hz
Rated speed	3490 rpm
Slip	3.06 %
Rated voltage	208-230/460 V
Rated current	1.79-1.62/0.811 A
L. R. Amperes	11.1-10.1/5.03 A
LRC	6.2x(Code K)
No load current	0.776-0.900/0.450 A
Rated torque	0.742 ft.lb
Locked rotor torque	229 %
Breakdown torque	280 %
Locked rotor time	70s (cold) 39s (hot)

Moment of inertia (J)	0.0389 sq.ft.lb
Insulation Class	F
Temperature rise	80 K
Service factor	1.25 (1.00 @ 208V)
Duty Cycle	Cont.(S1)
Starting Method	Direct On Line
Ambient temperature	-20?C to +40?C
Altitude	1000 m.a.s.l.
Enclosure	IC01 - ODP
Mounting	F-1
Rotation?	Both (CW and CCW)
Noise level?	62.0 dB(A)
Approx. weight?	16.4 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
64.0	70.0	73.4

Power factor

50%	75%	100%
0.57	0.69	0.78

Frame	56
Output	0.5 HP (0.37 kW)
Number of Poles	2
Frequency	50 Hz
Rated speed	2855 rpm
Slip	4.83 %
Rated voltage	190/380 V
Rated current	1.85/0.925 A
L. R. Amperes	8.88/4.44 A
LRC	4.8x(Code G)
No load current	0.880/0.440 A
Rated torque	0.907 ft.lb
Locked rotor torque	160 %
Breakdown torque	210 %
Locked rotor time	81s (cold) 45s (hot)

Moment of inertia (J)	0.0389 sq.ft.lb
Insulation Class	F
Service factor	1.25
Temperature rise	80 K
Service factor	1.25 (1.00 @ 208V)
Duty Cycle	Cont.(S1)
Starting Method	Direct On Line
Ambient temperature	-20?C to +40?C
Altitude	1000 m.a.s.l.
Enclosure	IC01 - ODP
Mounting	F-1
Rotation?	Both (CW and CCW)
Noise level?	60.0 dB(A)
Approx. weight?	16.4 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
67.0	71.3	71.5

Power factor

50%	75%	100%
0.65	0.78	0.85

Frame	56
Output	0.5 HP (0.37 kW)
Number of Poles	2
Frequency	50 Hz
Rated speed	2880 rpm
Slip	4.00 %
Rated voltage	220/415 V
Rated current	1.76/0.932 A
L. R. Amperes	9.14/4.85 A
LRC	5.2x(Code H)
No load current	1.35/0.714 A
Rated torque	0.899 ft.lb
Locked rotor torque	200 %
Breakdown torque	260 %
Locked rotor time	66s (cold) 37s (hot)

Moment of inertia (J)	0.0389 sq.ft.lb
Insulation Class	F
Service factor	1.25
Temperature rise	80 K
Service factor	1.25 (1.00 @ 208V)
Duty Cycle	Cont.(S1)
Starting Method	Direct On Line
Ambient temperature	-20?C to +40?C
Altitude	1000 m.a.s.l.
Enclosure	IC01 - ODP
Mounting	F-1
Rotation?	Both (CW and CCW)
Noise level?	60.0 dB(A)
Approx. weight?	16.4 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
62.1	68.5	70.8

Power factor

50%	75%	100%
0.55	0.68	0.78

Features

Frame Material	Rolled Steel
Impregnation Method	Dip and Bake Polyester
Shaft Material	SAE 1040/45 Carbon Steel
Painting	Only primer
Grounding Lugs	Single
Fan Cover material	Without Fan Cover
Tropicalized Painting	Without
Fan material	Without fan
Bearing cap	No-Without Bearing Cap
Bolt Material	Carbon Steel
Balancing Method	1/2 Key
Drip Cover	Without
Resilient Base	Without
