tem - Relay Multi-Function Timing Relay
Function - Timing Relay Cycle One Shot, Interval Delay, On Delay, Off Delay 1, Off Delay 2, Repeat Cycle Equal Off/On Time, Signal Interval/Off Delay, Signal On Delay/Off Delay

Coil Volts - 24 to 240VAC/12 to 240VDC
AC Contact Rating - Relay 3A @ 250V
Base Type - Plug In Relay Octal
Number of Pins - Relay 11
Mounting - Relay Plug In, Through Panel
Contact Form - Relay SPDT
Power Consumption - Relay 3.0VA, 3.0W
Adjustment Method - Timer Push Button
Min. Time Setting - Timer 0.10 sec.
Max. Time Setting - Timer 416 days 6 hr.
Status Indicator - LCD
Contact Material - Silver Alloy
Body Height - Relay 2.97"
Body Width - Relay 1.89"
Body Depth - Relay 1.89"
Overall Height - Relay 3.50"
Electrical Connection- Socket
Socket - 6X156, 1EGP2, 1EGP4
Hz - Electrical 50 Hz, 60 Hz
Standards- cULus, CE
