Motor/Control Division

Frame	M48Y
Output	2.5 HP (1.84 kW)
Number of Poles	2
Frequency	60 Hz
Rated speed	3450 rpm
Slip	4.17 %
Rated voltage	230 V
Rated current	10.8 A
L. R. Amperes	63.7 A
LRC	5.9x(Code G)
No load current	3.40 A
Rated torque	3.75 ft.lb
Locked rotor torque	170 %
Breakdown torque	210 %
Locked rotor time	10s (cold) 6s (hot)

Moment of inertia (J)	0.0446 sq.ft.lb
Insulation Class	B
Service factor	1.04
Temperature rise	70 K
Duty Cycle	Cont.(S1)
Starting Method	Direct On Line
Ambient temperature	-20°C to +50°C
Altitude	1000 m.a.s.l.
Degree of Protection	IP21
Enclosure	IC01 - ODP
Mounting	F-1
Rotation¹	CCW
Noise level²	58.0 dB(A)
Approx. weight³	32.0 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
0.000	79.0	80.7

Power factor

50%	75%	100%
0.00	0.00	0.93

Features

Frame Material	Rolled Steel
Impregnation Method	Dip and Bake Polyester
Shaft Material	AISI 316 Stainless Steel
Painting
Grounding Lugs	Single
Tropicalized Painting	Without
Fan material	Nylon
Bearing cap	Yes- Bearing Cap
Balancing Method	Not Balanced
Drip Cover	Without
Shaft End	threaded
Resilient Base	Without

Loading...

Bearing details

	Drive End	Non Drive End
Bearing type	6203 2RS	6203 2RS
Sealing	Lip Seal	Lip Seal
Lubrication interval	-	-
Lubricant amount	-	-
Grease Type	Mobil Polyrex EM
