Output0.500 hp
Phase1
Synchronous Speed900 rpm
Frequency60.00 Hz
Voltage115 V
230 V
Frame MaterialSteel
Frame56Z
XP Class and GroupNONE
XP DivisionNot Applicable
BrandBaldor-Reliance
Agency ApprovalsCSA
UR
Ambient Temperature40 °C
Auxillary BoxNo Auxillary Box
Auxillary Box Lead TerminationNone
Base IndicatorResilient
Bearing Grease TypePOLYREX EM (-20F +300F)
BlowerNone
Current9.2 A @ 115 V
4.6 A @ 230 V
Design Code-
Drip CoverNo Drip Cover
Duty RatingCONT
Efficiency @ 100% Load50.0%
Electrically Isolated BearingNot Electrically Isolated
Feedback DeviceNo feedback
Front Face CodeTerminal panel
Front Shaft IndicatorNone
Heater IndicatorNo heater
High Voltage Full Load Amps4.6 A
Insulation ClassB
Inverter CodeNot inverter
KVA CodeF
Lifting LugsNo Lifting Lugs
Locked Bearing IndicatorNo Locked Bearing
Motor Lead ExitTerminal Panel
Motor Lead Quantity/Wire Size6 @ 18 AWG
Motor Lead TerminationNone
Motor StandardsNEMA
Motor Type3535C
Number of Poles8
Overall Length14.42 in
Power Factor68
Product FamilyGeneral Purpose
Pulley End Bearing TypeSealed Bearing
Pulley Face CodeResilient Mount
Pulley Shaft IndicatorStandard
Rodent ScreenNone
Service Factor1.00
Shaft Diameter0.625 in
Shaft Extension LocationPulley End
Shaft Ground IndicatorNo Shaft Grounding
Shaft RotationReversible: Connected Standard
Shaft Slinger IndicatorNo Slinger
Speed825 rpm
Speed CodeSingle Speed
Starting MethodDirect on line
Thermal Device - BearingNONE (OLD)
Thermal Device - WindingNone
Vibration Sensor IndicatorNo Vibration Sensor
Winding Thermal 1Automatic Thermal Overload
Winding Thermal 1 LocationSB
Winding Thermal 2None
