$82.82 / Each

Quantity:

11697384, S-1, 180VAC 50Hz / 208VAC 60Hz Coil, No Auxiliary Contacts

Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1	1000 V
Rated insulation voltage Ui (pollution degree 3) - UL, CSA	600 V
Rated operational frequency - minimum	25 Hz
Rated operational frequency - maximum	400 Hz
Mechanical lifespan (AC)	10 million
Mechanical lifespan (DC)	10 million
Electrical lifespan	1,2 million
Degree of protection IP (IEC 60529) - Main circuit	IP10
Degree of protection IP (IEC 60529) - Control circuit	IP20

Rated current	32 A (N)
Rated current In - AC-4	16 A
Rated operational Current Ie AC-1 (¿ = 55 ºC)	60 A
Rated operational voltage Ue - IEC 60947-4-1	690 V
Rated operational voltage Ue - UL/CSA	600 V
Height	89 mm (3.50 in)
Width	55 mm (2.17 in)
Depth	98 mm (3.86 in)
Gross weight	1.2 kg

For Use With CWM32-40 and CWMC32

BCA4-40V23

$21.50 / Each

Number of Poles

Current

32 Amp
