$122.80 / Each

Quantity:

110VAC 50Hz / 120VAC 60Hz Coil, No Auxiliary Contacts

Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1	1000 V
Rated insulation voltage Ui (pollution degree 3) - UL, CSA	600 V
Rated operational frequency - minimum	25 Hz
Rated operational frequency - maximum	400 Hz
MECHANICAL LIFESPAN AC	10 million
MECHANICAL LIFESPAN DC	10 million
Electrical lifespan	1,3 million
Degree of protection IP (IEC 60529) - Main circuit	IP10
Degree of protection IP (IEC 60529) - Control circuit	IP20

Rated current In - AC-3 (Ue = 440 V)	65 A
Rated current In - AC-4	30 A
Rated operational Current Ie AC-1 (¿ = 55 ºC)	110 A
Rated operational voltage Ue - IEC 60947-4-1	1000 V
Rated operational voltage Ue - UL/CSA	600 V
Height	116.5 mm (4.59 in)
Width	66 mm (2.60 in)
Depth	116 mm (4.57 in)
Gross weight	11.6 kg

Number of Poles

Current

65 Amp

Series

CWM
