Motor/Control Division

Frame	112M
Output	2 HP (1.5 kW)
Number of Poles	8
Frequency	50 Hz
Rated speed	700 rpm
Slip	6.67 %
Rated voltage	380 V
Rated current	4.02 A
L. R. Amperes	20.1 A
LRC	5.0
No load current	2.40 A
Rated torque	14.8 ft.lb
Locked rotor torque	220 %
Breakdown torque	229 %
Locked rotor time	50s (cold) 28s (hot)

Moment of inertia (J)	0.5648 sq.ft.lb
Design	N
Insulation Class	F
Service factor	1.00
Temperature rise	80 K
Duty Cycle	S1
Starting Method	Direct On Line
Ambient temperature	-20Â°C to +40Â°C
Altitude	1000 m.a.s.l.
Degree of Protection	IP55
Enclosure	IC411 - TEFC
Mounting	B3L(E)
RotationÂ¹	Both (CW and CCW)
Noise levelÂ²	46.0 dB(A)
Approx. weightÂ³	84.3 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
79.0	79.5	79.8

Power factor

50%	75%	100%
0.49	0.63	0.71

Frame	112M
Output	2 HP (1.5 kW)
Number of Poles	8
Frequency	50 Hz
Rated speed	705 rpm
Slip	6.00 %
Rated voltage	400 V
Rated current	3.96 A
L. R. Amperes	19.8 A
LRC	5.0
No load current	2.60 A
Rated torque	14.7 ft.lb
Locked rotor torque	250 %
Breakdown torque	260 %
Locked rotor time	50s (cold) 28s (hot)

Moment of inertia (J)	0.5648 sq.ft.lb
Design	N
Insulation Class	F
Service factor	1.00
Temperature rise	80 K
Duty Cycle	S1
Starting Method	Direct On Line
Ambient temperature	-20Â°C to +40Â°C
Altitude	1000 m.a.s.l.
Degree of Protection	IP55
Enclosure	IC411 - TEFC
Mounting	B3L(E)
RotationÂ¹	Both (CW and CCW)
Noise levelÂ²	46.0 dB(A)
Approx. weightÂ³	84.3 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
79.0	80.5	80.5

Power factor

50%	75%	100%
0.45	0.59	0.68

Frame	112M
Output	2 HP (1.5 kW)
Number of Poles	8
Frequency	50 Hz
Rated speed	710 rpm
Slip	5.33 %
Rated voltage	415 V
Rated current	3.97 A
L. R. Amperes	21.0 A
LRC	5.3
No load current	2.80 A
Rated torque	14.6 ft.lb
Locked rotor torque	280 %
Breakdown torque	290 %
Locked rotor time	50s (cold) 28s (hot)

Moment of inertia (J)	0.5648 sq.ft.lb
Design	N
Insulation Class	F
Service factor	1.00
Temperature rise	80 K
Duty Cycle	S1
Starting Method	Direct On Line
Ambient temperature	-20Â°C to +40Â°C
Altitude	1000 m.a.s.l.
Degree of Protection	IP55
Enclosure	IC411 - TEFC
Mounting	B3L(E)
RotationÂ¹	Both (CW and CCW)
Noise levelÂ²	46.0 dB(A)
Approx. weightÂ³	84.3 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
77.9	80.2	80.8

Power factor

50%	75%	100%
0.42	0.56	0.65

Frame	112M
Output	2 HP (1.5 kW)
Number of Poles	8
Frequency	60 Hz
Rated speed	865 rpm
Slip	3.89 %
Rated voltage	460 V
Rated current	3.50 A
L. R. Amperes	20.7 A
LRC	5.9
No load current	2.45 A
Rated torque	12.0 ft.lb
Locked rotor torque	280 %
Breakdown torque	300 %
Locked rotor time	68s (cold) 38s (hot)

Moment of inertia (J)	0.5648 sq.ft.lb
Design	N
Insulation Class	F
Service factor	1.25
Temperature rise	80 K
Duty Cycle	S1
Starting Method	Direct On Line
Ambient temperature	-20Â°C to +40Â°C
Altitude	1000 m.a.s.l.
Degree of Protection	IP55
Enclosure	IC411 - TEFC
Mounting	B3L(E)
RotationÂ¹	Both (CW and CCW)
Noise levelÂ²	50.0 dB(A)
Approx. weightÂ³	84.3 lb

(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.

Efficiency

50%	75%	100%
77.0	80.0	84.0

Power factor

50%	75%	100%
0.44	0.57	0.64

Features

Frame Material	Aluminum
Impregnation Method	Dip and Bake Polyester
Main terminal box hole	2xM32x1,5
Terminal Block	BMC - 6 pins
Shaft Locking Device	Without
Drain	Rubber, automatic
Shaft Material	SAE 1040/45 Carbon Steel
Painting	RAL 5009 207A (ISO 12944 - C2)
Grounding Lugs	Single
Fan Cover material	Steel
Tropicalized Painting	Without
Fan material	Plastic
Bearing cap	No-Without Bearing Cap
Drip Cover	Without
