Output
1.000 hp
Phase
1
Synchronous Speed
3,600 rpm
Frequency
60.00 Hz
Voltage
230 V
115 V
Frame Material
Steel
Frame
56C
XP Class and Group
NONE
XP Division
Not Applicable
Brand
Baldor-Reliance
Agency Approvals
CSA
UR
Ambient Temperature
40 °C
Auxillary Box
No Auxillary Box
Auxillary Box Lead Termination
None
Base Indicator
Rigid
Bearing Grease Type
POLYREX EM (-20F +300F)
Blower
None
Current
11.8 A @ 115 V
6.1 A @ 208 V
5.9 A @ 230 V
Design Code
N
Drip Cover
No Drip Cover
Duty Rating
CONT
Efficiency @ 100% Load
68.0%
Electrically Isolated Bearing
Not Electrically Isolated
Feedback Device
No feedback
Front Face Code
Standard
Front Shaft Indicator
None
Heater Indicator
No heater
High Voltage Full Load Amps
5.9 A
Insulation Class
F
Inverter Code
Not inverter
KVA Code
K
Lifting Lugs
No Lifting Lugs
Locked Bearing Indicator
Locked Bearing
Motor Lead Exit
KO Box
Motor Lead Quantity/Wire Size
4 @ 16 AWG, A PH
Motor Lead Termination
Flying Leads
Motor Standards
NEMA
Motor Type
3520L
Number of Poles
2
Overall Length
12.23 in
Power Factor
82
Product Family
Wash Down
Pulley End Bearing Type
Sealed Bearing
Pulley Face Code
C-Face
Pulley Shaft Indicator
Standard
Rodent Screen
None
RoHS Status
RoHS Compliant
Service Factor
1.25
Shaft Diameter
0.625 in
Shaft Extension Location
Pulley End
Shaft Ground Indicator
No Shaft Grounding
Shaft Rotation
Reversible
Shaft Slinger Indicator
Shaft Slinger
Speed
3,450 rpm
Speed Code
Single Speed
Starting Method
Direct on line
Thermal Device - Bearing
None
Thermal Device - Winding
None
Vibration Sensor Indicator
No Vibration Sensor
Winding Thermal 1
None
Winding Thermal 2
None
