/Products/Electric Motors/Single Phase Electric Motors/Marathon Single Phase Electric Motors/131538.00 Marathon 5HP General Purpose Electric Motor, 1800RPM
Click Image to Expand

Product ID: 131538.00

131538.00 Marathon 5HP General Purpose Electric Motor, 1800RPM

MFG: Marathon Electric
MFG Part Number: 131538.00

Selected accessories will also be added to cart
$909.97 / Each
Quantity:
TEFC, 184T Frame, 230VAC Single Phase 60Hz, Rigid Base, Rolled Steel, 1-1/8" Keyed Shaft

Features

  • Durable rolled steel construction
  • NEMA Design B performance
  • Double shielded ball bearings
  • Continuous duty
  • Thermally protected ratings

General Specifications

UPC:691720017869Weight:98.00 LB
Packaged Length:20.13 INPackaged Width:14.63 IN
Packaged Height:12.38 IN

Nameplate Specifications

Output HP:5 HpOutput KW:3.7 kW
Frequency:60 HzVoltage:230 V
Current:23.0 ASpeed:1740 rpm
Service Factor:1Phase:1
Efficiency:81 %Power Factor:92
Duty:ContinuousInsulation Class:F
Design Code:LKVA Code:H
Frame:184TEnclosure:Totally Enclosed Fan Cooled
Thermal Protection:NoAmbient Temperature:40 ?C
Drive End Bearing Size:6206Opp Drive End Bearing Size:6205
UL:RecognizedCSA:Y
CE:NIP Code:43

Technical Specifications

Electrical Type:Capacitor Start Capacitor RunStarting Method:Across The Line
Poles:4Rotation:Selective Counterclockwise
Resistance Main:0 OhmsMounting:Rigid Base
Motor Orientation:HorizontalDrive End Bearing:Ball
Opp Drive End Bearing:BallFrame Material:Rolled Steel
Shaft Type:TOverall Length:17.46 in
Frame Length:12.00 inShaft Diameter:1.125 in
Shaft Extension:2.75 inAssembly/Box Mounting:F1 ONLY

Speed & Load Characteristics

Speed Characteristics

CurvepointCurrent (Amps)Current (%)Torque (ft-lbs)(%)Speed (RPM)Rated Output (KW)Power Factor (%)Rated Output (Hp)
Full Load23.0015.00100.005.00
Pull-Up0.0030.50203.005.00
Locked-Rotor149.0046.50310.005.00
Break-Down0.0035.30235.005.00

Load Characteristics

% of Rated Load0 %25 %50 %75 %100 %125 %150 %
Current (Amps)7.708.9812.6116.7521.7027.5434.35
Rated Output (KW)0.431.292.313.394.595.747.17
Efficiency (%)0.073.982.383.681.680.977.1
Power Factor (%)24.362.579.587.992.090.690.8
Speed (RPM)1,7981,7901,7811,7711,7581,7441,728
Temp. Rise @ FL0.00.00.00.098.00.00.0
Torque (ft-lbs)0.003.757.5011.2515.0018.7522.50
Type
Electric Motor
Input Phase
Single Phase
Speed
1800RPM
Enclosure
TEFC
Horsepower
5HP
Frame
184T
