/Products/Electric Motors/Single Phase Electric Motors/Marathon Single Phase Electric Motors/131857.00 Marathon 3HP Electric Motor, 1800RPM
Click Image to Expand

Product ID: 131857.00

131857.00 Marathon 3HP Electric Motor, 1800RPM

MFG: Marathon Electric
MFG Part Number: 131857.00

Selected accessories will also be added to cart
$786.86 / Each
Quantity:
P14K17FK14B, 184TC Frame, 208-230VAC Single Phase 60Hz, TEFC, C-Face with Base, Rolled Steel, 1-1/8" Keyed Shaft
Features
  • Double shielded ball bearings
  • Dynamically balanced rotors
  • Capacitor start / capacitor run designs to reduce amp draw
  • Manual reset overload protection
  • High service factor
General Specifications
Model :P14K17FK14 BCatalog No :131857.00
Part Description :3HP..1750RPM.184.TEFC./V.1PH.60HZ.CONT.MANUAL.40C.1.15SF.RIGID.PRESSURE WASHER.184TBFR7749APCategory :Totally Enclosed Fan Cooled (TEFC)
Stock :No
Nameplate Specifications
Output HP :3 HpOutput KW :2.24 kW
Frequency :60 HzVoltage :230 V
Current :12.8 ASpeed :1755 rpm
Service Factor :1.15 Phase :1
Efficiency :81.5 %Duty :CONTINUOUS
Insulation Class :F Design Code :L
KVA Code :H Frame :184TC
Enclosure :TEFC Overload Protector :MANUAL
Ambient Temperature :40 ?CDrive End Bearing Size :6206
Opp Drive End Bearing Size :6205 UL :Recognized
CSA :Y CE :N
IP Code :43
Technical Specifications
Electrical Type :CAP START CAP RUN Starting Method :ACROSS THE LINE
Poles :4 Rotation :SELECTIVE CCW
Mounting :RIGID Motor Orientation :HORIZONTAL
Drive End Bearing :BALL Opp Drive End Bearing :BALL
Frame Material :ROLLED STEEL Shaft Type :T
Overall Length :14.97 inFrame Length :9.5 in
Shaft Diameter :1.13 inShaft Extension :2.75 in
Assembly/Box Mounting :F1 ONLY UPC :691720154540
Weight :107.00 LB
Speed Characteristics
CurvepointCurrent (Amps)Current (%)Torque (ft-lbs)Torque (%)Speed (RPM)Rated Output (KW)Power Factor (%)Rated Output (Hp)
Locked-Rotor90.00734.023.50263.0020.400.03.00
Break-Down48.00375.023.50263.01,56010.400.03.00
Full Load12.80100.08.94100.01,7552.750.03.00
Pull-Up68.00531.017.60197.01,24012.100.03.00
Load Characteristics
  • % of Rated Load
  • Current (Amps)
  • Rated Output (KW)
  • Efficiency (%)
  • Power Factor (%)
  • Speed (RPM)
  • Temp. rise @ FL
  • Torque (ft-lb)
  • 0 %
  • 3.80
  • 0.380
  • 0.0
  • 43.5
  • 1,800
  • 0.0
  • 0.00
  • 25 %
  • 5.10
  • 0.920
  • 60.6
  • 78.4
  • 1,784
  • 0.0
  • 2.20
  • 50 %
  • 7.30
  • 1.495
  • 74.5
  • 89.0
  • 1,773
  • 0.0
  • 4.42
  • 75 %
  • 9.90
  • 2.100
  • 79.9
  • 92.2
  • 1,762
  • 0.0
  • 6.70
  • 100 %
  • 12.80
  • 2.730
  • 81.5
  • 94.5
  • 1,755
  • 65.0
  • 8.94
  • 115 %
  • 14.50
  • 3.160
  • 80.9
  • 94.8
  • 1,740
  • 78.0
  • 10.34
  • 125 %
  • 15.80
  • 3.450
  • 80.5
  • 94.9
  • 1,737
  • 0.0
  • 11.25
  • 150 %
  • 19.50
  • 4.250
  • 78.2
  • 94.8
  • 1,721
  • 0.0
  • 13.60
Type
Electric Motor
Input Phase
Single Phase
Speed
1800RPM
Horsepower
3HP
Frame
184TC
