/Products/Electric Motors/Single Phase Electric Motors/Marathon Single Phase Electric Motors/131994.00 Marathon 3HP Hi-Torque Agriculture Duty Electric Motor, 1800RPM
Click Image to Expand

Product ID: 131994.00

131994.00 Marathon 3HP Hi-Torque Agriculture Duty Electric Motor, 1800RPM

MFG: Marathon Electric
MFG Part Number: P184C17FK10

Selected accessories will also be added to cart
$778.06 / Each
Quantity:
TEFC, 184TC Frame, 230VAC Single Phase 60Hz, P184C17FK10A, C-Face, Rigid Base, Rolled Steel, 1-1/8" Shaft

Features

  • Gasketed capacitor cases and conduit box covers
  • Meets or exceeds NEMA ? service factors
  • Manual rest overload protection
  • UL recognized component listing and CSA certified

General Specifications

General Specifications

UPC:691720328798Weight:107.00 LB
Packaged Length:20.13 INPackaged Width:14.63 IN
Packaged Height:12.38 IN

Nameplate Specifications

Nameplate Specifications

Output HP:3 HpOutput KW:2.2 kW
Frequency:60 HzVoltage:230 V
Current:19.0 ASpeed:1740 rpm
Service Factor:1.15Phase:1
Efficiency:75.5 % Power Factor:68
Duty:ContinuousInsulation Class:F
Design Code:LKVA Code:K
Frame:184TCEnclosure:Totally Enclosed Fan Cooled
Thermal Protection:ManualAmbient Temperature:40 ?C
Drive End Bearing Size:6205Opp Drive End Bearing Size:6206
UL:RecognizedCSA:Y
CE:NIP Code:43
Number of Speeds:1

Technical Specifications

Technical Specifications

Electrical Type:Capacitor Start Induction RunStarting Method:Across The Line
Poles:4Rotation:Selective Counterclockwise
Resistance Main:.498 OhmsMounting:Rigid Base
Motor Orientation:HorizontalDrive End Bearing:Ball
Opp Drive End Bearing:BallFrame Material:Rolled Steel
Shaft Type:TOverall Length:16.47 in
Frame Length:11.00 inShaft Diameter:1.125 in
Shaft Extension:2.75 inAssembly/Box Mounting:F1 ONLY

Speed Characteristics

Speed Characteristics

CurvepointCurrent (Amps)Current (%)Torque (LB-FT)Torque (%)Speed (RPM)Rated Output (KW)Power Factor (%)Rated Output (Hp)
Pull-Up0.0023.50261.003.00
Break-Down0.0027.85309.003.00
Locked-Rotor136.0037.45416.003.00
Full Load19.009.00100.01,7693.00

Load Characteristics

Load Characteristics

% of Rated Load0 %25 %50 %75 %100 %115 %125 %150 %
Current (Amps)13.6014.0015.3017.1019.0020.5021.9025.00
Rated Output (KW)0.521.151.772.383.003.203.744.52
Efficiency (%)0.049.964.471.675.575.475.374.2
Power Factor (%)16.635.650.360.568.571.274.378.7
Speed (RPM)1,7971,7901,7841,7771,7701,7651,7611,750
Temp. Rise @ FL0.00.00.00.091.00.00.00.0
Torque (LB-FT)0.002.254.506.759.0010.0011.2513.50
Type
Electric Motor
Input Phase
Single Phase
Speed
1800RPM
Enclosure
TEFC
Horsepower
3HP
Enclosure
TEFC
Frame
184TC
